Facilities

  1. 1.Well Equipped Laboratories:
  2. As per AICTE norms, we have eight well-equipped laboratories, classroom with modern teaching aids.

  1. 2. Software Detail :
Lab No. Name Of Lab Major Equipment’s and Software’s
1 Communication Lab
  1. 1. Colour TV Trainer with Pattern Generator
  2. 2. LCD Trainer Kit
  3. 3. Fiber Optics Kit
  4. 4. Amplitude & Frequency Modulation & Demodulation Kit.
2 Advanced Communication Lab
  1. 1. Microwave test bench kit (Klystron)
  2. 2. Antenna Trainer Kit
  3. 3. Radar Trainer Kit
  4. 4. Digital Communication kits
  5. 5. Digital Oscilloscope (DSO)
3 Analog Electronics Lab
  1. 1. Dual Power Supply
  2. 2. CRO, Function Generator
  3. 3. LCR & LCR Q Meter
  4. 4. Op-Amp Kits
4 Digital & Microcontroller Lab
  1. 1. VLSI Kits (CPLD, FPGA)
  2. 2. Microcontroller Kits (Arm 7, PIC, 8051)
  3. 3. Displacement, weight & speed measurement kit
  4. 4. Bridge circuits
5 Programming Lab
  1. 1. Computers
  2. 2. MATLAB
  3. 3. Simulink
  4. 4. Simscape
Sr. No. Software Name
1 MATLAB 2016 (Simulink, Signal Processing, Image Processing, DSP,Simscaps, Control System toolbox)
2 Keil v2, Keil v3
3 Xilinx 10.0
4 AMS
5 ORCAD
6 Proteus 8
