Facilities

Name Of Lab Major Equipment’s and Software’s
Measurements and Instruments Lab
  1. 1. Single & Three phase energy meter
  2. 2. Megger Trainer kit
  3. 3. LVDT Displacement measurement Trainer
  4. 4. Wheatstone Bridge Kit
  • i) Control System Lab
  • ii) Power System Lab
  1. 1. Computers
  2. 2. MATLAB
  3. 3. Simulink
  4. 4. AutoCad
Advanced Switchgear and Protection Lab
  1. 1. Directional over current relay
  2. 2. Earth fault relay
  3. 3. Over current relay
  4. 4. Microprocessor based Directional over current relay
  5. 5. Microprocessor based Earth fault relay

  • i)Power Electronics Lab
  • ii)Analog Electronics Engineering
  1. 1. Single phase half and full controlled bridge converter
  2. 2. Single phase cycloconverter
  3. 3. Full wave bridge rectifier using SCR and UJT
  4. 4. Bridge circuits
  5. 5. Op-amp
  • i)Electrical Machines Lab
  • ii)Electrical Drives Lab
  1. 1. Three phase squirrel-cage Induction motor
  2. 2. Three phase Slip-ring Induction motor
  3. 3. DC Shunt motor
  4. 4. Alternator
  5. 5. DC Generator
  6. 6. Three phase full converter (Bridge Rectifier)
  7. 7. DC series motor using chopper
  8. 8. DC shunt motor from three phase fully controlled
  • i)Basic Electrical Lab
  • ii)Testing & Maintenance Lab
  1. 1. Three phase squirrel-cage Induction motor
  2. 2. Three phase Slip-ring Induction motor
  3. 3. DC Shunt motor
  4. 4. Alternator
  5. 5. DC Generator
  6. 6. Three phase full converter (Bridge Rectifier)
  7. 7. DC series motor using chopper
  8. 8. DC shunt motor from three phase fully controlled
  • i) Micro-Processor & Micro-controller
  • ii) Electrical Machine Design
  1. 1. Auto-Cad
  2. 2. Computer
  3. 3. Microcontroller 8051 Trainer kit
  4. 4. Microcontroller 8085 classic kit
  5. 5. Microcontroller development board
  6. 6. PCM modulation / Demodulation

?????????
